HiGHS¶

class HiGHS(*args)¶

Linear optimization solver.

Warning

This class is experimental and likely to be modified in future releases. To use it, import the openturns.experimental submodule.

This class exposes the linear solver from the HiGHS library. It is only meant to be used with linear mixed-integer optimization problems.

Parameters:

problemOptimizationProblem: The problem

Methods

`getCheckStatus`()	Accessor to check status flag.
`getClassName`()	Accessor to the object's name.
`getMaximumAbsoluteError`()	Accessor to maximum allowed absolute error.
`getMaximumCallsNumber`()	Accessor to maximum allowed number of calls.
`getMaximumConstraintError`()	Accessor to maximum allowed constraint error.
`getMaximumIterationNumber`()	Accessor to maximum allowed number of iterations.
`getMaximumRelativeError`()	Accessor to maximum allowed relative error.
`getMaximumResidualError`()	Accessor to maximum allowed residual error.
`getMaximumTimeDuration`()	Accessor to the maximum duration.
`getName`()	Accessor to the object's name.
`getProblem`()	Accessor to optimization problem.
`getResult`()	Accessor to optimization result.
`getStartingPoint`()	Accessor to starting point.
`getStartingSample`()	Accessor to starting sample.
`hasName`()	Test if the object is named.
`run`()	Launch the optimization.
`setCheckStatus`(checkStatus)	Accessor to check status flag.
`setMaximumAbsoluteError`(maximumAbsoluteError)	Accessor to maximum allowed absolute error.
`setMaximumCallsNumber`(maximumCallsNumber)	Accessor to maximum allowed number of calls
`setMaximumConstraintError`(maximumConstraintError)	Accessor to maximum allowed constraint error.
`setMaximumIterationNumber`(maximumIterationNumber)	Accessor to maximum allowed number of iterations.
`setMaximumRelativeError`(maximumRelativeError)	Accessor to maximum allowed relative error.
`setMaximumResidualError`(maximumResidualError)	Accessor to maximum allowed residual error.
`setMaximumTimeDuration`(maximumTime)	Accessor to the maximum duration.
`setName`(name)	Accessor to the object's name.
`setProblem`(problem)	Accessor to optimization problem.
`setProgressCallback`(*args)	Set up a progress callback.
`setResult`(result)	Accessor to optimization result.
`setStartingPoint`(startingPoint)	Accessor to starting point.
`setStartingSample`(startingSample)	Accessor to starting sample.
`setStopCallback`(*args)	Set up a stop callback.

See also

openturns.experimental.LinearProblem

Notes

HiGHS solver can be adapted using the parameters described here. These parameters can be modified through the ResourceMap. For every option optionName, simply add a key named HiGHS-optionName with the value to use, as shown below:

>>> import openturns as ot
>>> ot.ResourceMap.AddAsBool('HiGHS-output_flag', True)
>>> ot.ResourceMap.AddAsUnsignedInteger('HiGHS-threads', 4)

HiGHS prefers to solve problems with at least one integer (or binary) variable, but this is not actually enforced.

Examples

Solve a mixed integer linear optimization problem with objective:

f = 1.1 x_0 + x_1

with inequality constraints:

$\begin{eqnarray*} & x_1 & \leq 7\\ 5 & \leq x_0 + 2x_1 & \leq 15\\ 6 & \leq 3x_0 + 2x_1 & \\ \end{eqnarray*}$

and bound constraints:

$\begin{eqnarray*} 0 & \leq x_0 & \leq 4\\ 1 & \leq x_1 & \end{eqnarray*}$

>>> import openturns as ot
>>> import openturns.experimental as otexp
>>> cost = [1.1, 1.0]
>>> bounds = ot.Interval([0.0, 1.0], [4.0, 1e30])
>>> A = ot.Matrix([[0.0, 1.0], [1.0, 2.0], [3.0, 2.0]])
>>> cb = ot.Interval([-1e9, 5.0, 6.0], [7.0, 15.0, 1e9])
>>> problem = otexp.LinearProblem(cost, bounds, A, cb)
>>> problem.setVariablesType([ot.OptimizationProblemImplementation.INTEGER] * 2)
>>> algo = otexp.HiGHS(problem)
>>> algo.run()
>>> result = algo.getResult()
>>> x_star = result.getOptimalPoint()
>>> y_star = result.getOptimalValue()

__init__(*args)¶

getCheckStatus()¶

Accessor to check status flag.

Returns:

checkStatusbool: Whether to check the termination status. If set to False, run() will not throw an exception if the algorithm does not fully converge and will allow one to still find a feasible candidate.

getClassName()¶

Accessor to the object’s name.

Returns:

class_namestr: The object class name (object.__class__.__name__).

getMaximumAbsoluteError()¶

Accessor to maximum allowed absolute error.

Returns:

maximumAbsoluteErrorfloat: Maximum allowed absolute error, where the absolute error is defined by $\epsilon^a_n=\|\vect{x}_{n+1}-\vect{x}_n\|_{\infty}$ where $\vect{x}_{n+1}$ and $\vect{x}_n$ are two consecutive approximations of the optimum.

getMaximumCallsNumber()¶

Accessor to maximum allowed number of calls.

Returns:

maximumEvaluationNumberint: Maximum allowed number of direct objective function calls through the () operator. Does not take into account eventual indirect calls through finite difference gradient calls.

getMaximumConstraintError()¶

Accessor to maximum allowed constraint error.

Returns:

maximumConstraintErrorfloat: Maximum allowed constraint error, where the constraint error is defined by $\gamma_n=\|g(\vect{x}_n)\|_{\infty}$ where $\vect{x}_n$ is the current approximation of the optimum and $g$ is the function that gathers all the equality and inequality constraints (violated values only)

getMaximumIterationNumber()¶

Accessor to maximum allowed number of iterations.

Returns:

maximumIterationNumberint: Maximum allowed number of iterations.

getMaximumRelativeError()¶

Accessor to maximum allowed relative error.

Returns:

maximumRelativeErrorfloat: Maximum allowed relative error, where the relative error is defined by $\epsilon^r_n=\epsilon^a_n/\|\vect{x}_{n+1}\|_{\infty}$ if $\|\vect{x}_{n+1}\|_{\infty}\neq 0$ , else $\epsilon^r_n=-1$ .

getMaximumResidualError()¶

Accessor to maximum allowed residual error.

Returns:

maximumResidualErrorfloat: Maximum allowed residual error, where the residual error is defined by $\epsilon^r_n=\frac{\|f(\vect{x}_{n+1})-f(\vect{x}_{n})\|}{\|f(\vect{x}_{n+1})\|}$ if $\|f(\vect{x}_{n+1})\|\neq 0$ , else $\epsilon^r_n=-1$ .

getMaximumTimeDuration()¶

Accessor to the maximum duration.

Returns:

maximumTimefloat: Maximum optimization duration in seconds.

getName()¶

Accessor to the object’s name.

Returns:

namestr: The name of the object.

getProblem()¶

Accessor to optimization problem.

Returns:

problemOptimizationProblem: Optimization problem.

getResult()¶

Accessor to optimization result.

Returns:

resultOptimizationResult: Result class.

getStartingPoint()¶

Accessor to starting point.

Returns:

startingPointPoint: Starting point.

getStartingSample()¶

Accessor to starting sample.

Returns:

startingSampleSample: Starting sample.

hasName()¶

Test if the object is named.

Returns:

hasNamebool: True if the name is not empty.

run()¶: Launch the optimization.

setCheckStatus(checkStatus)¶

Accessor to check status flag.

Parameters:

checkStatusbool: Whether to check the termination status. If set to False, run() will not throw an exception if the algorithm does not fully converge and will allow one to still find a feasible candidate.

setMaximumAbsoluteError(maximumAbsoluteError)¶

Accessor to maximum allowed absolute error.

Parameters:

maximumAbsoluteErrorfloat: Maximum allowed absolute error, where the absolute error is defined by $\epsilon^a_n=\|\vect{x}_{n+1}-\vect{x}_n\|_{\infty}$ where $\vect{x}_{n+1}$ and $\vect{x}_n$ are two consecutive approximations of the optimum.

setMaximumCallsNumber(maximumCallsNumber)¶

Accessor to maximum allowed number of calls

Parameters:

maximumEvaluationNumberint: Maximum allowed number of direct objective function calls through the () operator. Does not take into account eventual indirect calls through finite difference gradient calls.

setMaximumConstraintError(maximumConstraintError)¶

Accessor to maximum allowed constraint error.

Parameters:

maximumConstraintErrorfloat: Maximum allowed constraint error, where the constraint error is defined by $\gamma_n=\|g(\vect{x}_n)\|_{\infty}$ where $\vect{x}_n$ is the current approximation of the optimum and $g$ is the function that gathers all the equality and inequality constraints (violated values only)

setMaximumIterationNumber(maximumIterationNumber)¶

Accessor to maximum allowed number of iterations.

Parameters:

maximumIterationNumberint: Maximum allowed number of iterations.

setMaximumRelativeError(maximumRelativeError)¶

Accessor to maximum allowed relative error.

Parameters:

maximumRelativeErrorfloat: Maximum allowed relative error, where the relative error is defined by $\epsilon^r_n=\epsilon^a_n/\|\vect{x}_{n+1}\|_{\infty}$ if $\|\vect{x}_{n+1}\|_{\infty}\neq 0$ , else $\epsilon^r_n=-1$ .

setMaximumResidualError(maximumResidualError)¶

Accessor to maximum allowed residual error.

Parameters:

maximumResidualErrorfloat: Maximum allowed residual error, where the residual error is defined by $\epsilon^r_n=\frac{\|f(\vect{x}_{n+1})-f(\vect{x}_{n})\|}{\|f(\vect{x}_{n+1})\|}$ if $\|f(\vect{x}_{n+1})\|\neq 0$ , else $\epsilon^r_n=-1$ .

setMaximumTimeDuration(maximumTime)¶

Accessor to the maximum duration.

Parameters:

maximumTimefloat: Maximum optimization duration in seconds.

setName(name)¶

Accessor to the object’s name.

Parameters:

namestr: The name of the object.

setProblem(problem)¶

Accessor to optimization problem.

Parameters:

problemOptimizationProblem: Optimization problem.

setProgressCallback(*args)¶

Set up a progress callback.

Can be used to programmatically report the progress of an optimization.

Parameters:

callbackcallable: Takes a float as argument as percentage of progress.

Examples

>>> import sys
>>> import openturns as ot
>>> rosenbrock = ot.SymbolicFunction(['x1', 'x2'], ['(1-x1)^2+100*(x2-x1^2)^2'])
>>> problem = ot.OptimizationProblem(rosenbrock)
>>> solver = ot.OptimizationAlgorithm(problem)
>>> solver.setStartingPoint([0, 0])
>>> solver.setMaximumResidualError(1.e-3)
>>> solver.setMaximumCallsNumber(10000)
>>> def report_progress(progress):
...     sys.stderr.write('-- progress=' + str(progress) + '%\n')
>>> solver.setProgressCallback(report_progress)
>>> solver.run()

setResult(result)¶

Accessor to optimization result.

Parameters:

resultOptimizationResult: Result class.

setStartingPoint(startingPoint)¶

Accessor to starting point.

Parameters:

startingPointPoint: Starting point.

setStartingSample(startingSample)¶

Accessor to starting sample.

Parameters:

startingSampleSample: Starting sample.

setStopCallback(*args)¶

Set up a stop callback.

Can be used to programmatically stop an optimization.

Parameters:

callbackcallable: Returns an int deciding whether to stop or continue.

Examples

>>> import openturns as ot
>>> rosenbrock = ot.SymbolicFunction(['x1', 'x2'], ['(1-x1)^2+100*(x2-x1^2)^2'])
>>> problem = ot.OptimizationProblem(rosenbrock)
>>> solver = ot.OptimizationAlgorithm(problem)
>>> solver.setStartingPoint([0, 0])
>>> solver.setMaximumResidualError(1.e-3)
>>> solver.setMaximumCallsNumber(10000)
>>> def ask_stop():
...     return True
>>> solver.setStopCallback(ask_stop)
>>> solver.run()

Examples using the class¶

Optimization using HiGHS solver
